This square pipe punching machine is NC control, for punching & drawing tapered holes on round tubes,copper,stainless steel,aluminum,steel, etc., especially the flute tube for solar pipe and air conditioner pipe purpose.
I Main features of the square pipe punching machine:
l Servo feeding, hydraulic forming
l NC control, convenient operation
l Good punching & drawing result, high efficient
II Main technical data of the square pipe punching machine:
III Structure and configuration of the square pipe punching machine
3.1 Composition: main body, feeding device, punching device, rotating device, clamping device, hydraulic system, electric control system and cooling system.
3.2 Hydraulic station is equipped with air cooling system.
3.3 Hydraulic valves and pump are from Taiwan
3.4 PLC + touch screen control from Japan; Servo motor is from Taiwan
3.5 Control system has automatic counting function which can count processing quantity.
3.6 Processing data can be pre-set and saved in the PLC and can be recalled for next time use.
IV Supplying range of the square pipe punching machine:
4.1 Complete machine
4.2 One set of punching die (according to Buyer’s drawing)
4.3 Operation manual, electric drawing, hydraulic drawing
4.4 Tool kit
Kindly please contact us for more service or details of the square pipe punching machine.
