Yuantaiderun Square Hollow Section Astm A36 Square Pipe Factories

Short Description:

• 23+ years of experience in steel pipe manufacturing
• Professional project engineering orders
• Strict inspection before delivery

Thickness: 0.5 - 60 mm

OD(outer diameter) : rectangular:10*15 800*1100mm

Certification: CE,LEED,BV,PHD&EPD,BC1,JIS,ISO

Length: 1-24M

Standards: Hollow section: ASTM A500/A501,EN10219/10210,JIS G3466,GB/T6728/3094 AS1163, CSA G40.20/G40.21

Materials: Gr.A/B/C,S235/275/355/420/460,A36,SS400,Q195/235/355,STKR400/490,300W/350W

Delivery Time: 7-30 Days

Payment method: TT/LC

Tolerance: ±5% or as required

Send email to us Download as PDF

Product Detail

QUALITY CONTROL

FEED BACK

Product Tags

ASTM A36 is a standard specification that defines the mechanical properties and chemical composition of carbon steel materials. The A36 standard is applicable to a variety of structural steel products, including but not limited to steel plates, round steel, flat steel, angle steel, and steel pipes. It is widely used in construction, bridges, machinery manufacturing, and other fields due to its good mechanical properties and processing characteristics.

Features of ASTM A36 Square Tube:
◆ Moderate Strength: The yield strength of A36 material is at least 36,000 psi (about 250 MPa), which makes it strong enough for many applications.
◆ Good Weldability and Processability: This steel is easy to weld and cut by various methods and can be conveniently combined with other materials.
◆ Cost-effective: Due to its universality and production efficiency, A36 steel generally provides a cost-effective choice.

Specification of square and rectangular hollow sections

OD(MM)	THICKNESS(MM)	OD(MM)	THICKNESS(MM)	OD(MM)	THICKNESS(MM)	OD(MM)	THICKNESS(MM)
20*20	1.3	60120 80100 90*90	1.50	180*180	3	300800 400700 550550 500600
	1.4		1.70		3.5-3.75		9.5-9.75
	1.5		1.80		4.5-4.75		11.5-11.75
	1.7		2.00		5.5-7.75		12-13.75
	1.8		2.20		9.5-9.75		15-50
	2.0		2.5-4.0		11.5-11.75
2030 2525	1.3		4.25-4.75		12.0-25.0
	1.4		5.0-6.3	100300 150250 200*200	2.75	300900 400800 600600 500700
	1.5		7.5-8		3.0-4.0		9.5-9.75
	1.7	50150 60140 80120 100100	1.50		4.5-9.75		11.5-11.75
	1.8		1.70		11.5-11.75		12-13.75
	2.0		2.00		12.5-12.75		15-50
	2.2		2.20		13.5-13.75
	2.5-3.0		2.5-2.75		15.5-30
2040 2540 3030 3040	1.3		3.0-4.75	150300 200250	3.75	3001000 400900 500800 600700 650*650
	1.4		5.5-6.3		4.5-4.75
	1.5		7.5-7.75		5.5-6.3		9.5-9.75
	1.7		9.5-9.75		7.5-7.75		11.5-11.75
	1.8		11.5-16		9.5-9.75		12-13.75
	2.0	60160 80140 100*120	2.50		11.5-11.75		15-50
	2.2		2.75		13.5-30
	2.5-3.0		3.0-4.75	200300 250250	3.75	4001000 500900 600800 700700
	3.25-4.0		5.5-6.3		4.5-4.75
2550 3050 3060 4040 4050 4060 50*50	1.3		7.5-7.75		5.5-6.3		9.5-9.75
	1.4		9.5-16		7.5-7.75		11.5-11.75
	1.5	75*150	2.50		9.5-9.75		12-13.75
	1.7		2.75		11.5-11.75		15-50
	1.8		3.0-3.75		12-13.75
	2.0		4.5-4.75		15.5-30
	2.2		5.5-6.3	200400 250350 300*300	4.5-6.3	5001000 600900 700800 750750
	2.5-3.0		7.5-7.75		7.5-7.75		9.5-9.75
	3.25-4.0		9.5-16		9.5-9.75		11.5-11.75
	4.25-4.75	80160 120120	2.50		11.5-11.75		12-13.75
	5.0-5.75		2.75		12-13.75		15-50
	5.75-6.3		3.0-4.75		15.5-30
4080 5070 5080 6060	1.3		5.5-6.3	200500 250450 300400 350350	5.5-6.3	5001100 600900 700800 750750
	1.5		7.5-7.75		7.5-7.75		9.5-9.75
	1.7		9.5-9.75		9.5-9.75		11.5-11.75
	1.8		11.5-20		11.5-11.75		12-13.75
	2.0	100*150	2.50		12-13.75		15-50
	2.2		2.75		15.5-30
	2.5-3.0		3.0-4.75	280*280	5.5-6.3	6001100 7001000 800900 850850
	3.25-4.0		5.5-6.3		7.5-7.75		9.5-9.75
	4.25-4.75		7.5-7.75		9.5-9.75		11.5-11.75
	5.0-6.0		9.5-9.75		11.5-11.75		12-13.75
40100 6080 70*70	1.3		11.5-20		12-13.75		15-50
	1.5	100200 120180 150*150	2.50		15.5-30
	1.7		2.75	350400 300450	7.5-7.75	7001100 8001000 900*900
	1.8		3.0-7.75		9.5-9.75		11.5-11.75
	2.0		9.5-9.75		11.5-11.75		12-13.75
	2.2		11.5-20		12-13.75		15-50
	2.5-3.0	100250 150200	3.00		15.5-30
	3.25-4.0		3.25-3.75	200600 300500 400*400	7.5-7.75	8001100 9001000 950*950
	4.25-4.75		4.25-4.75		9.5-9.75		11.5-11.75
	5.0-6.3		9.5-9.75		11.5-11.75		12-13.75
50100 6090 60100 7575 80*80	1.3		11.5-11.75		12-13.75		15-50
	1.5		12.25		15.5-40
	1.7	140*140	3.0-3.75	300600 400500 400*400	7.5-7.75	9001100 10001000 800*1200
	1.8		4.5-6.3		9.5-9.75
	2.0		7.5-7.75		11.5-11.75		20-60
	2.2		9.5-9.75		12-13.75
	2.5-3.0		11.5-25		15.5-40
	3.25-4.0	160*160	3.00	400600 500500	9.5-9.75	11001000 11001100
	4.25-4.75		3.5-3.75		11.5-11.75		20-60
	5.0-5.75		4.25-7.75		12-13.75
	7.5-8		9.5-25		15.5-40

Specification of circular hollow sections

外径external diameter		壁厚wall thickness			重量weight
英寸Inches	毫米.millimeter	单位unit	毫米.millimeter	英寸.Inches	公斤/米.Kg/m	磅/英尺Pounds per foot.
1/8”	10.3	10S	1.24	0.049	0.28	0.19
1/8”	10.3	STD-40	1.73	0.068	0.37	0.25
1/8”	10.3	XS-80	2.41	0.095	0.48	0.32
1/4”	13.7	10S	1.65	0.065	0.50	0.34
1/4”	13.7	STD-40	2.24	0.088	0.64	0.43
1/4”	13.7	XS-80	3.02	0.119	0.81	0.55
3/8”	17.1	10S	1.65	0.065	0.64	0.43
3/8”	17.1	STD-40	2.31	0.091	0.85	0.57
3/8”	17.1	XS-80	3.20	0.126	1.11	0.75
1/2”	21.3	5S	1.05	0.042	0.53	0.36
1/2”	21.3	10S	2.11	0.083	1.01	0.68
1/2”	21.3	STD-40	2.77	0.109	1.28	0.86
1/2”	21.3	XS-80	3.73	0.147	1.63	1.10
1/2”	21.3	160	4.78	0.188	1.97	1.33
1/2”	21.3	XXS	7.47	0.294	2.57	1.73
3/4”	26.7	5S	1.65	0.065	1.03	0.69
3/4”	26.7	10S	2.11	0.083	1.29	0.87
3/4”	26.7	STD-40	2.87	0.113	1.70	1.14
3/4”	26.7	XS-80	3.91	0.154	2.22	1.49
3/4”	26.7	160	5.56	0.219	2.93	1.97
3/4”	26.7	XXS	7.82	0.308	3.68	2.48
1”	33.4	5S	1.65	0.065	1.31	0.88
1”	33.4	10S	2.77	0.109	2.12	1.42
1”	33.4	STD-40	3.38	0.133	2.53	1.70
1”	33.4	XS-80	4.55	0.179	3.27	2.18
1”	33.4	160	6.35	0.250	4.28	2.88
1”	33.4	XXS	9.09	0.358	5.51	3.71
1 1/4”	42.2	5S	1.65	0.065	1.67	1.12
1 1/4”	42.2	10S	2.77	0.109	2.72	1.83
1 1/4”	42.2	STD-40	3.56	0.140	3.43	2.31
1 1/4”	42.2	XS-80	4.85	0.191	4.51	3.03
1 1/4”	42.2	160	6.35	0.250	5.67	3.81
1 1/4”	42.2	XXS	9.70	0.382	7.85	5.28
1 1/2”	48.3	5S	1.65	0.065	1.92	1.29
1 1/2”	48.3	10S	2.77	0.109	3.14	2.11
1 1/2”	48.3	STD-40	3.68	0.145	4.09	2.75
1 1/2”	48.3	XS-80	5.08	0.200	5.47	3.68
1 1/2”	48.3	160	7.14	0.281	7.32	4.92
1 1/2”	48.3	XXS	10.15	0.400	9.65	6.49
2”	60.3	5S	1.65	0.065	2.41	1.62
2”	60.3		2.11	0.083	3.06	2.06
2”	60.3	10S	2.77	0.109	3.97	2.67
2”	60.3		3.18	0.125	4.52	3.04
2”	60.3	STD-40	3.91	0.154	5.49	3.69
2”	60.3	XS-80	5.54	0.218	7.56	5.08
2”	60.3	160	8.74	0.344	11.23	7.55
2”	60.3	XXS	11.07	0.436	13.58	9.13
2 1/2”	73.0	5S	2.11	0.083	3.73	2.51
2 1/2”	73.0	10S	3.05	0.120	5.32	3.57
2 1/2”	73.0	30	4.78	0.188	8.12	5.46
2 1/2”	73.0	STD-40	5.16	0.203	8.72	5.86
2 1/2”	73.0	XS-80	7.01	0.276	11.52	7.74
2 1/2”	73.0	160	9.53	0.375	15.08	10.14
2 1/2”	73.0	XXS	14.02	0.552	20.60	13.84
3”	88.9	5S	2.11	0.083	4.56	3.07
3”	88.9		2.77	0.109	5.95	4.00
3”	88.9	10S	3.05	0.120	6.52	4.38
3”	88.9		3.18	0.125	6.79	4.56
3”	88.9		3.58	0.141	7.61	5.12
3”	88.9		3.96	0.156	8.38	5.63
3”	88.9	STD-40	5.49	0.216	11.41	7.67
3”	88.9	XS-80	7.62	0.300	15.43	10.37
3”	88.9	160	11.13	0.438	21.56	14.49
3”	88.9	XXS	15.24	0.600	27.96	18.79
3 1/2”	101.6	5S	2.11	0.083	5.23	3.52
3 1/2”	101.6	10S	3.05	0.120	7.49	5.03
3 1/2”	101.6	30	4.78	0.188	11.53	7.75
3 1/2”	101.6	STD-40	5.74	0.226	13.71	9.21
3 1/2”	101.6	XS-80	8.08	0.318	18.83	12.65
4”	114.3	5S	2.11	0.083	5.90	3.97
4”	114.3	10S	3.05	0.120	8.46	5.68
4”	114.3		3.18	0.125	8.81	5.92
4”	114.3		3.96	0.156	10.89	7.32
4”	114.3		4.37	0.172	11.97	8.05
4”	114.3		4.78	0.188	13.04	8.76
4”	114.3		5.16	0.203	14.03	9.43
4”	114.3		5.56	0.219	15.06	10.62
4”	114.3	STD-40	6.02	0.237	16.24	10.91
4”	114.3		6.35	0.250	17.08	11.48
4”	114.3		7.14	0.281	19.06	12.81
4”	114.3		7.92	0.312	20.99	14.11
4”	114.3	XS-80	8.56	0.337	22.55	15.15
4”	114.3	120	11.13	0.438	28.61	19.23
4”	114.3	160	13.49	0.531	33.88	22.77
4”	114.3	XXS	17.12	0.674	41.45	27.85
5”	141.3		3.96	0.156	13.55	9.11
5”	141.3		4.78	0.188	16.26	10.93
5”	141.3		5.56	0.219	18.80	12.63
5”	141.3	STD-40	6.55	0.258	21.99	14.78
5”	141.3		7.14	0.281	23.86	16.04
5”	141.3		7.92	0.312	26.32	17.69
5”	141.3	XS-80	9.53	0.375	31.28	21.02
5”	141.3	120	12.70	0.500	40.69	27.34
5”	141.3	160	15.88	0.625	49.62	33.34
5”	141.3	XXS	19.05	0.750	58.01	38.98
6”	168.3		4.37	0.172	17.84	11.99
6”	168.3		4.78	0.188	19.47	13.09
6”	168.3		5.16	0.203	20.97	14.09
6”	168.3		5.56	0.219	22.54	15.15
6”	168.3		6.35	0.250	25.62	17.22
6”	168.3	STD-40	7.11	0.280	28.55	19.19
6”	168.3		7.92	0.312	31.64	21.26
6”	168.3		8.74	0.344	34.74	23.35
6”	168.3		9.53	0.375	37.69	25.33
6”	168.3	XS-80	10.97	0.432	42.99	28.89
6”	168.3		12.70	0.500	49.23	33.08
6”	168.3	120	14.27	0.562	54.75	36.79
6”	168.3		15.88	0.625	60.30	40.52
6”	168.3	160	18.26	0.719	68.25	45.86
6”	168.3		19.05	0.750	70.85	47.61
6”	168.3	XXS	21.95	0.864	80.02	53.77
6”	168.3		22.23	0.875	80.87	54.34
8”	219.1		4.78	0.188	25.52	17.15
8”	219.1		5.16	0.203	27.50	18.48
8”	219.1		5.56	0.219	29.58	19.88
8”	219.1	20	6.35	0.250	33.65	22.61
8”	219.1	30	7.04	0.277	37.19	24.99
8”	219.1		7.92	0.312	41.66	28.00
8”	219.1	STD-40	8.18	0.322	42.98	28.88
8”	219.1		8.74	0.344	45.80	30.78
8”	219.1		9.53	0.375	49.75	33.43
8”	219.1	60	10.31	0.406	53.62	36.03
8”	219.1		11.13	0.438	57.66	38.75
8”	219.1	XS-80	12.70	0.500	65.30	43.88
8”	219.1		14.27	0.562	72.81	48.93
8”	219.1	100	15.09	0.594	76.69	51.53
8”	219.1		15.88	0.625	80.31	54.02
8”	219.1	120	18.26	0.719	91.36	61.39
8”	219.1		19.05	0.750	94.93	63.79
8”	219.1	140	20.62	0.812	101.95	68.51
8”	219.1	XXS	22.23	0.875	108.96	73.22
8”	219.1	160	23.01	0.906	112.40	75.59
8”	219.1		25.40	1.000	122.56	82.36
10”	273.0		4.78	0.188	31.94	21.46
10”	273.0		5.16	0.203	34.43	23.14
10”	273.0		5.56	0.219	37.04	24.89
10”	273.0	20	6.35	0.250	42.18	28.34
10”	273.0		7.09	0.279	46.97	31.56
10”	273.0	30	7.80	0.307	51.53	34.63
10”	273.0		8.74	0.344	57.34	38.66
10”	273.0	STD-40	9.27	0.365	60.90	40.92
10”	273.0		11.13	0.438	72.61	48.79
10”	273.0	XS-60	12.70	0.500	82.35	55.34
10”	273.0		14.27	0.562	91.92	61.80
10”	273.0	80	15.09	0.594	96.95	65.15
10”	273.0		15.88	0.625	101.71	68.35
10”	273.0	100	18.26	0.719	115.87	77.86
10”	273.0		20.62	0.812	129.64	87.11
10”	273.0	120	21.44	0.844	134.35	90.28
10”	273.0		22.23	0.875	138.87	93.32
10”	273.0		23.83	0.938	147.91	99.39
10”	273.0	XXS-140	25.40	1.000	156.66	105.22
10”	273.0	160	28.58	1.125	174.01	116.93
10”	273.0		31.75	1.250	190.81	128.22
12”	323.8	20	6.35	0.250	50.22	33.75
12”	323.8		7.14	0.281	56.32	37.85
12”	323.8		7.92	0.312	62.32	41.88
12”	323.8	30	8.38	0.330	65.85	44.23
12”	323.8		8.74	0.344	68.60	46.10
12”	323.8	STD	9.53	0.375	74.61	50.13
12”	323.8	40	10.31	0.406	80.51	54.10
12”	323.8		11.13	0.438	86.69	58.25
12”	323.8	XS	12.70	0.500	98.42	66.14
12”	323.8	60	14.27	0.562	110.03	73.94
12”	323.8		15.88	0.625	121.81	81.85
12”	323.8	80	17.48	0.688	133.38	89.63
12”	323.8		19.05	0.750	14.62	97.18
12”	323.8		20.62	0.812	155.73	104.65
12”	323.8	100	21.44	0.844	161.48	108.51
12”	323.8		23.83	0.938	178.07	119.65
12”	323.8	XXS-120	25.40	1.000	188.80	126.87
12”	323.8		26.97	1.062	199.42	134.00
12”	323.8	140	28.58	1.125	210.18	141.23
12”	323.8		31.75	1.250	230.98	155.21
12”	323.8	160	33.32	1.312	241.10	162.01
14”	355.6	10	6.35	0.250	55.25	37.13
14”	355.6	20	7.92	0.312	68.60	46.1
14”	355.6		8.74	0.344	75.52	50.75
14”	355.6	STD-30	9.53	0.375	82.16	55.21
14”	355.6		10.31	0.406	88.68	59.59
14”	355.6	40	11.13	0.438	95.51	64.18
14”	355.6	XS	12.70	0.500	108.48	72.90
14”	355.6		14.27	0.562	121.33	81.53
14”	355.6	60	15.09	0.594	128.00	86.01
14”	355.6	80	19.05	0.750	159.71	107.32
14”	355.6	100	23.83	0.938	196.94	132.34
14”	355.6		25.40	1.000	208.92	140.39
14”	355.6		26.97	1.062	220.78	148.36
14”	355.6	120	27.79	1.094	226.93	152.49
14”	355.6	140	31.75	1.250	256.13	172.11
14”	355.6	160	35.71	1.406	284.56	191.21
16”	406.4	10	6.35	0.250	63.28	42.52
16”	406.4		7.14	0.281	71.01	47.72
16”	406.4	20	7.92	0.312	78.62	52.83
16”	406.4		8.74	0.344	86.58	58.18
16”	406.4	STD-30	9.53	0.357	94.21	63.31
16”	406.4		10.31	0.406	101.72	68.36
16”	406.4		11.13	0.438	109.59	73.64
16”	406.4	XS-40	12.70	0.500	124.55	83.69
16”	406.4		14.27	0.562	139.39	93.67
16”	406.4		15.88	0.625	154.48	103.80
16”	406.4	60	16.66	0.656	161.74	108.69
16”	406.4		17.48	0.688	169.35	113.80
16”	406.4		19.05	0.750	183.81	123.52
16”	406.4		20.62	0.812	198.15	133.15
16”	406.4	80	21.44	0.844	205.60	138.15
16”	406.4		25.40	1.000	241.06	161.98
16”	406.4	100	26.19	1.031	248.05	166.68
16”	406.4	120	30.96	1.219	289.54	194.56
16”	406.4		31.75	1.250	296.31	199.11
16”	406.4	140	36.53	1.438	336.57	226.16
16”	406.4	160	40.49	1.594	369.06	247.99
18”	457	20	7.92	0.312	88.60	59.54
18”	457		8.74	0.344	97.59	65.58
18”	457	STD	9.53	0.375	106.23	71.38
18”	457		10.31	0.406	114.72	77.09
18”	457	30	11.13	0.438	123.62	83.07
18”	457	XS	12.70	0.500	140.56	94.45
18”	457	40	14.27	0.562	157.38	105.75
18”	457		15.88	0.625	174.50	117.25
18”	457		17.48	0.688	191.38	128.60
18”	457	60	19.05	0.750	207.82	139.65
18”	457	80	23.83	0.938	257.13	172.78
18”	457		25.40	1.000	273.08	183.50
18”	457		26.97	1.062	288.91	194.14
18”	457		28.58	1.125	305.01	204.96
18”	457	100	29.36	1.156	312.76	210.16
18”	457		30.18	1.188	320.88	215.62
18”	457		31.75	1.250	336.33	226.00
18”	457	120	34.93	1.375	367.25	246.78
18”	457	140	39.67	1.562	412.40	277.12
18”	457	160	45.24	1.781	464.03	311.81
20”	508		8.74	0.344	108.70	73.04
20”	508	STD-20	9.53	0.375	118.33	79.51
20”	508		10.31	0.406	127.82	85.89
20”	508		11.13	0.438	137.76	92.57
20”	508	XS-30	12.70	0.500	156.70	105.3
20”	508		14.27	0.562	175.51	117.94
20”	508	40	15.09	0.594	185.28	124.50
20”	508		15.88	0.625	194.67	130.81
20”	508		17.48	0.688	213.59	143.53
20”	508		19.05	0.750	232.03	155.92
20”	508	60	20.62	0.812	250.34	168.22
20”	508		25.40	1.000	305.35	205.18
20”	508	80	26.19	1.031	314.33	211.22
20”	508		30.18	1.188	359.22	241.38
20”	508		31.75	1.250	376.66	253.10
20”	508	100	32.54	1.281	385.40	258.97
20”	508	120	38.10	1.500	445.97	299.67
20”	508	140	44.45	1.750	513.27	344.90
20”	508	160	50.01	1.969	570.54	383.38
22”	559		8.74	0.344	119.80	80.5
22”	559	STD-20	9.53	0.375	130.44	87.65
22”	559	XS-30	12.70	0.500	172.83	116.14
22”	559		15.88	0.625	214.84	144.37
22”	559		17.48	0.688	235.79	158.44
22”	559		19.05	0.750	256.23	172.18
22”	559		20.62	0.812	276.54	185.83
24”	610		8.74	0.344	130.90	87.96
24”	610	STD-20	9.53	0.375	142.55	95.79
24”	610	XS	12.70	0.500	188.96	126.98
24”	610	30	14.27	0.562	211.76	142.30
24”	610		15.88	0.625	233.02	157.93
24”	610	40	17.48	0.688	258.00	173.37
24”	610		19.05	0.750	280.43	188.44
24”	610		20.62	0.812	302.73	203.42
24”	610	60	24.61	0.969	358.87	241.15
24”	610		25.40	1.000	369.89	248.55
24”	610		26.97	1.062	391.69	263.20
24”	610		30.18	1.188	435.90	292.91
24”	610	80	30.96	1.219	442.86	297.59
24”	610	100	38.89	1.531	553.26	371.72
24”	610	120	46.02	1.812	646.52	434.44
24”	610	140	52.37	2.062	727.45	488.82
26”	660	STD	9.53	0.375	154.42	103.77
26”	660	XS-20	12.70	0.500	204.78	137.61
26”	660		17.48	0.688	279.77	188.00
26”	660		19.05	0.750	304.15	204.38
28”	711	STD	9.53	0.375	166.52	118.90
28”	711	XS-20	12.70	0.500	220.91	148.44
28”	711		17.48	0.688	301.98	202.92
28”	711		19.05	0.750	328.35	220.64
30”	762	STD	9.53	0.375	178.63	120.03
30”	762	XS-20	12.70	0.500	237.05	159.29
32”	813	STD	9.53	0.375	190.74	128.17
32”	813	XS-20	12.70	0.500	253.18	170.13
34”	864	STD	9.53	0.375	202.84	136.30
34”	864	XS-20	12.70	0.500	269.31	180.97
36”	914	STD	9.53	0.375	214.71	144.28
36”	914	XS-20	12.70	0.500	285.13	191.60
38”	965	STD	9.53	0.375	226.82	152.42
38”	965	XS	12.70	0.500	301.27	202.44
40”	1016	STD	9.53	0.375	238.93	160.55
40”	1016	XS	12.70	0.500	317.40	213.28
42”	1067	STD	9.53	0.375	251.04	168.69
42”	1067	XS	12.70	0.500	333.54	224.13
44”	1118	STD	9.53	0.375	263.14	176.82
44”	1118	XS	12.70	0.500	349.67	234.92
46”	1168	STD	9.53	0.375	275.01	184.80
46”	1168	XS	12.70	0.500	365.49	245.59
48”	1219	STD	9.53	0.375	287.12	192.93
48”	1219	XS	12.70	0.500	381.62	256.43
52”	1321		9.53	0.375	311.33	209.20
52”	1321		12.70	0.500	413.89	278.12
56”	1422		9.53	0.375	335.31	225.32
56”	1422		12.70	0.500	445.84	299.59
60”	1524		9.53	0.375	359.52	241.50
60”	1524		12.70	0.500	478.11	321.27
64”	1626		9.53	0.375	383.74	257.86
64”	1626		12.70	0.500	510.38	342.96
68”	1727		12.70	0.500	542.33	364.43
72”	1829		12.70	0.500	574.60	386.11
76”	1930		12.70	0.500	606.55	407.58
80”	2032		14.27	0.562	717.23	481.95

Astm A36 Square Pipe Application areas:

◆Construction industry: used to build frame structures, support members, etc. A36 square tubes are widely used in modern buildings because of their regular shape and easy installation.
◆Engineering structures: such as bridge construction, road guardrails, etc. Its excellent mechanical properties make it an ideal choice for outdoor projects.
◆Mechanical equipment manufacturing: It can be used to manufacture work platforms, ladders and other mechanical parts that need to withstand certain loads.

Factory

Laboratory testing

PRODUCT ADVANTAGES

01 Performance index analysis of square tube - good plasticity

Plasticity refers to the ability of metal materials to produce plastic deformation (permanent deformation) without damage under load.

02 Performance index analysis of square tube - high hardness

Hardness is a pointer to measure the hardness of metal materials. At present, the most commonly used hardness measurement method in production is the indentation hardness method, which uses an indenter with a certain geometric shape to press into the surface of the metal material to be tested under a certain load, and determines its hardness value according to the degree of indentation.

Common methods include Brinell hardness (HB), Rockwell hardness (HRA, HRB, HRC) and Vickers hardness (HV).

3 CERTIFICATION IS
COMPLETE
can produce steel pipe products of world
stardard,such as European standard,American standard,
Japanese standard,Astralian standard,natinal standard
and so on.

04 Performance index analysis of square tube - good impact toughness
The load acting on the machine at a high speed is called impact load, and the ability of metal to resist damage under impact load is called impact toughness.

HOT PRODUCTS

Q1: Are you trading company or manufacturer ?

A: We are factory.

Q2: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 30 days if the goods are not in stock, it is according to quantity.

Q3:Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge with the cost of freight paid by customer.

Q4: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD 30% T/T in advance ,balance before shippment.If you have another question, pls feel free to contact us as below

Previous: Tianjin Yuantai black hollow steel square tube

Next: High Quality Corrosion Resistant Q235 Q355 Seamless Steel Pipe

The company attaches great importance to the quality of products, invests heavily in the introduction of advanced equipment and professionals, and goes all out to meet the needs of customers at home and abroad.
The content can be roughly divided into: chemical composition, yield strength, tensile strength, impact property, etc
At the same time, the company can also carry out on-line flaw detection and annealing and other heat treatment processes according to customer needs.

https://www.ytdrintl.com/

E-mail :sales@ytdrgg.com

Tianjin YuantaiDerun Steel Tube Manufacturing Group Co., Ltd. is a steel pipe factory certified by EN/ASTM/ JIS specializing in the production and export of all kinds of square rectangular pipe, galvanized pipe, ERW welded pipe, spiral pipe, submerged arc welded pipe, straight seam pipe, seamless pipe, color coated steel coil, galvanized steel coil and other steel products.With convenient transportation, it is 190 kilometers away from Beijing Capital International Airport and 80 kilometers away from Tianjin Xingang.

Whatsapp:+8613682051821

ASTM A36
