Wholesale Erw Welded steel pipe for construction

Short Description:

Material: Q235B, Q345B, ASTM A36/A53, JIS G3444
Size range:
Outer diameter: 21.3mm ~ 610mm (larger sizes can be customized).
Wall thickness: 1.0mm ~ 20mm.
Length: 6m/12m fixed length, or cut according to customer needs.
Implementation standards: GB/T 3091, API 5L, ASTM A53, EN 10219, etc.

Application: Structural type or fluid transportation

Technique: ERW

Certification: CE,LEED,BV,PHD&EPD,BC1,EN10210,EN10219,ISO9000,ASTMA500,ASTM A501,AS1163,JIS G3466

Tolerance: as required

Brand: YUANTAI DERUN

Length: 3-12M according to client requirement

Standards: Hollow section: ASTM A500/501,EN10219/10210, JIS G3466,GB/T6728/T3094/3091,CSA G40.20/G40.21

Materials: Gr.A/B/C,S235/275/355/420/460,A36,SS400,Q195/235/345,X42/52/60/65/70,STKR400/490,300W/350W

MOQ: 2-5 Tons

Packaging: Moisture/rust prevention measures, whether labeling

Delivery Time: 7-30 Days

After sales terms: Handling of quality issues during the warranty period

Payment method: TT/LC

Send email to us Download as PDF

Product Detail

QUALITY CONTROL

FEED BACK

Product Tags

Tianjin Yuantai Derun wholesale erw black round steel welded pipe Manufacturer

Product Overview

•Definition: ERW (electric resistance welding) steel pipe adopts high-frequency current welding process, suitable for low-pressure fluid transportation, building structure and other fields.

•Features: high weld strength, high production efficiency, low cost, smooth surface without burrs.

Erw Tube Manufacturing Process

Yuantai's products

Precision high-frequency resistance welding process

Adopting high-frequency welding equipment imported from Germany, the weld is uniform and free of oxides, and passes 100% online ultrasonic testing.

Ultra-wide size coverage capability

Outer diameter 21.3-1220mm, wall thickness 1.0-25mm (industry leading), support non-standard customization (such as special-shaped sections).

High-strength material system

Core material: Q355B (national standard), API 5L X42-X60 (American standard), tensile strength ≥520MPa (10% higher than the industry).

Intelligent anti-corrosion technology

Optional hot-dip galvanizing (zinc layer ≥85μm), 3PE coating (acid and alkali resistant), nano-epoxy paint (-30℃ weather resistant).

Yuantai's Differentiated Advantages

1. Process advantages

Yuantai Derun's exclusive "dual-frequency welding" technology, the weld strength reaches 95% of the parent material, eliminating the defect of unfused.

2. Delivery efficiency

Regular orders are delivered in 15 days (the industry average is 25 days), and urgent orders support 72-hour expedited production (requires +8% fee).

3. Cost control

Scaled production + self-developed raw material ratio, the price of the same specification is 5%-8% lower than the market.

4. Green certification

Complies with the EU RoHS environmental protection standards and provides carbon footprint reports (in line with the ESG needs of overseas customers).

ERW (Electric Resistance Welded) steel pipe

ERW materials construction steel pipe standard specification：

out diameter		Wall thickness	Length
Inch	mm	mm	meter
1/2	21.3mm	0.6mm-3.0mm	0.3m-12m
3/4	26.9mm	0.6mm-3.0mm	0.3m-12m
1	33.4mm	1.0mm-3.0mm	0.3m-12m
1-1/4	42.3mm	1.0mm-4.0mm	0.3m-12m
1-1/2	48.3mm	1.0mm-4.0mm	0.3m-12m
2	60.3mm	1.5mm-4.0mm	0.3m-12m
2-1/2	76.1mm	1.5mm-4.0mm	0.3m-12m
3	88.9mm	1.5mm-9.5mm	0.3m-12m
4	114.3mm	2.0mm-9.5mm	0.3m-12m
5	141.3mm	3.0mm-9.5mm	0.3m-12m
6	168.3mm	3.0mm-12.0mm	1.0m-12m
8	219.1mm	3.2mm-12.0mm	1.0m-12m
10	273mm	3.2mm-12.0mm	1.0m-12m
12	323.8mm	6.0mm-15.0mm	1.0m-12m
14	355.6mm	8.0mm-15.0mm	1.0m-12m
16	406.4mm	8.0mm-20.0mm	1.0m-12m
18	457.2mm	8.0mm-20.0mm	1.0m-12m
20	508.0mm	8.0mm-20.0mm	1.0m-12m
22	558.8mm	8.0mm-20.0mm	1.0m-12m
24	609.6mm	8.0mm-20.0mm	1.0m-24m

Company Profile

Professional supply of construction project orders

Tianjin Yuantai Derun is the largest manufacturer of ERW square rectangular pipes, hollow pipes, galvanized pipes, and spiral welded pipes in China. It is also one of the top 500 private enterprises and manufacturing enterprises in China. The company has an annual production capacity of 10 million tons and owns over 100 steel pipe production lines and more than 100 steel hollow section technology patents. The production types include ERW. LSAW, HFW, SSAW, seamless, hot-rolled, cold drawn, hot worked, etc

EQUIPMENT DISPLAY

HOT PRODUCTS

CERTIFICATE SHOW

PACKAGING

FAQ

Q1: What is the difference between ERW steel pipe and seamless pipe?

A: ERW has welds but meets the strength standards, while seamless pipes have no welds but are more expensive and are suitable for high-pressure scenarios.

Q2: Can you produce non-standard wall thickness ?

A: Yes, mold compatibility and additional costs need to be confirmed.

Q3:Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge with the cost of freight paid by customer.

Q4: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD 30% T/T in advance ,balance before shippment.If you have another question, pls feel free to contact us as below
